AV4M2-RN2-005-JS00-100
AirBorn FOCuS
Model
AV4M2-RN2-005-JS00-100
AV4M2--RN2-005-JS00-100
Supplier
Shenzhen Zhilian Technology Co., Ltd.
Stock Status
Inquiry Required
Physical Characteristics
bootType
Straight
cableLength
5.0m
cableSize
Not Applicable
Circuits (Loaded)
50
Max Circuits
50
Resin Color
Gray
durabilityMatingCyclesMax
2500
fiberCoreCladding
50/125µm
Gender
Plug-Plug
Lock
Yes
lockingType
Jacking Screws
Plating (Mating End)
Gold
Resin Material
Liquid Crystal Polymer (LCP)
materialShell
Aluminum Alloy
numberOfColumns
10
Number of Rows
5
orientation
Straight-to-Straight
Packaging
ESD Tray
Pitch
0.050" (1.27mm)
pitchTerminationInterface
0.050" (1.27mm)
platingMinMating
50µ”
platingShell
Electroless Nickel
polarization
A
singleEnded
No
Operating Temperature
-55° to +125°C
wireCableType
Non-Radiation Hardened OM3 Fiber
Electrical Characteristics
Rated Current (per Contact)
2.0A
dataRate
50.0 Gbps
dielectricWithstandingVoltageV
600
voltageInput
3.3V
Documents & Resources
2 DocumentsDatasheet
(datasheet)specifications
(specifications)Compliance
EU RoHS
EU RoHS Directive
Not Reviewed
REACH SVHC
EU REACH Regulation
Not Reviewed
EU ELV
EU ELV Directive
Not Reviewed
California Prop 65
CA Proposition 65
China RoHS
China RoHS
Not Reviewed
Low-Halogen
Low Halogen Standard
Not Reviewed
GADSL/IMDS
GADSL
No tooling data available
Additional Info
3D Model
Unavailable
About AV4M2-RN2-005-JS00-100
Shenzhen Zhilian Technology Co., Ltd. professionally supplies AV4M2-RN2-005-JS00-100 (AirBorn FOCuS), This is a Molex brand 连接器 (通用) connector. AirBorn FOCuS Active Optical Cable Assembly, Plug with Jacking Screws, Rugged, 0.050" (1.27mm) Pitch, 50 Circuits, 5.0m Length
Technical features: Max circuits 50; Pitch 0.050" (1.27mm); Type: Plug-Plug; Operating temp -55° to +125°C; Rated current 2.0A;
Stock status: Inquiry Required, Ref. Price: Inquiry / Negotiate. For inquiries or more specs, call +86 18879756080.
|
